Model 497.01 Analog Chassis

About Analog Chassis Slots

Slot pairing

Slot assignments

Slot A
Slot B
Slots 1–4
Slots 5–8
Slots 9–12
Slots 13–16
MTS 793 Controller Hardware
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chassis slot assignments are grouped in pairs. If you have a
conditioner in a slot, then you cannot have a valve driver installed in
the slot paired with it. Slots are paired as follows:
Slots 1–2 Slots 9–10
Slots 3–4 Slots 11–12
Slots 5–6 Slots 13–14
Slots 7–8 Slots 15–16
The analog chassis contains 18 bus-board slots for plug-in modules.
Each slot is reserved for a particular type of plug-in module.
Reserved for the Model 497.34 Multistation Interlock Module.
Reserved for the Model 497.36 Communications Module.
These slots are reserved for up to four AC conditioners.
These slots are reserved for up to four DC conditioners.
These slots are reserved for options (not used with standard systems).
These slots are reserved for up to four valve drivers.
Installing 497/498 Electronics (FTIIm)
Installation 61
