J49 Auxiliary Power - MTS Systems FlexTest IIm Manual

P N
IN
1 intlk in 24V
2 intlk in high
3 intlk in low
4 intlk in comm
5 N/C
6 intlk out NO
7 intlk out COM
8 intlk out NC
9 N/C
Cable specification
Power
characteristics
Jumper plug required

J49 Auxiliary Power

MTS 793 Controller Hardware
