Note The operational sequence in the following step may not be intuitive.
This sequence is necessary because of how the 793 and 407
Controllers are cabled together. The following step assumes that at
power up, hydraulics are off, the 793 Controller has a hydraulic and a
program interlock active, and the 407 Controller has a hydraulic
interlock active.
6. Apply the program.
To apply the program from the 793 Controller to 407 Controller:
A. On the Station Manager application's Station Controls
panel, click Reset to clear the Hydraulic interlock.
B. On the Station Manager application's Station Controls
panel, click HPU Power Low and then HPU Power High to
turn on the HPU.
C. On the Station Manager application's Station Controls
panel, click HSM Power Low and then HSM Power High to
turn on the HSM.
D. On the 407 Controller, clear the hydraulic Interlock:
– Press the Alt Function button.
– Press the Reset button ("9" on the key pad). The
Interlock indicator on the front panel should extinguish.
E. On the 407 Controller, apply hydraulic pressure with the
Hydraulic Pressure buttons.
F. On the 407 Controller, press Run. This step readies the 407
Controller to receive program from the 793 Controller.
G. On the Station Manager application's Station Controls
panel, click Reset to clear the Program interlock.
H. On the Station Manager application's Station Controls
panel, click the
program from the 793 Controller to the 407 Controller.
(Program Run). This step sends
