M M N
ODEL ODULE AME
493.71 RS485
493.72 Digital I/O
493.73 HPU Transition Board
493.74 HSM Transition Board
493.75 Analog In BNC
493.76 Analog Out BNC
493.77 Filtered Analog Input
493.78 Accelerometer Transition
Board
493.79 Multiple Universal Driver
Board
493.80 Encoder Transition
493.81 Analog In BNC
493.82 Analog Out BNC
493.83 Filtered Analog Input
MTS 793 Controller Hardware
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Rear Panel Transition Panels

F
UNCTION
Provides four channels of RS-485 interface, four channels of
station stop interlocks, and four channels of emergency stop
interlocks. The RS-485 interface channels are used for the
Remote Station Controller and/or temperature controller.
Contains sixteen general purpose digital input channels and
sixteen general purpose digital output channels.
Interfaces the controller with a hydraulic power unit.
Interfaces the controller with a hydraulic service manifold and
other devices, up to two stations.
Provides six BNC channels for analog input signals. The input
signals must be within ±10 V DC.
Provides six BNC channels for analog output signals. The
output signals are within ±10 V DC.
Provides filtering for the Model 493.45 A/D (analog-to-digital)
modules.
Interfaces with up to three low impedance voltage mode
(LIVM) accelerometers and three signal conditioned type
accelerometers.
Provides up to six drivers that can be used to drive standard
252 servovalves. Inputs to this board can originate from
either a ADDA II board (6 outputs) or a Model 493.46
D/A board (6 outputs).
Interfaces with up to four encoders.
Provides up to eight channels of analog input to each Model
493.55 A/D module. The input signals must be within ±10 V
DC.
Provides eight channels of analog output from the Model
493.56 D/A modules. The output signals are within ±10 V DC.
Provides up to eight channels of filtered analog input to each
Model 493.55 A/D module.
