Installing the 493.02 Chassis (FlexTest SE)

Installing the Handle Kit

56
Installation
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
The Controller may be equipped with an optional handle kit.
The following procedure provides assembly and installation
instructions for the handle kit (MTS PN 100-061-494). The following
table and figure show the handle kit assembly components described
in the procedure.
I D
TEM ESCRIPTION
1 Support arm
2 Handle side leg
3
4 Washer
5 Screw
6 Spring
7 Button
8 Ratchet
9 Ratchet housing
10 Lock washer
11 Handle screw
12 Handle
13 Cover

Handle Kit Parts

Clip
MTS 793 Controller Hardware
Q
UANTITY
2
2
2
4
2
2
2
2
2
2
2
1
2
