Encoder/Temposonics Connections

Model 498.65
ADDA Module
ADDA
Encoder
498.65 +/-Ex
ADDA
J1
A
D
R
S
FAIL
RESET
J
1
1 J2
J
1
2
J
1
3
J3
J
1
4
E
X
T
J4
J
1
5
OR
J11
J
1
6
J J12
1
7
J
1
8
MTS 793 Controller Hardware
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Encoders and Temposonics® sensors are connected to the FlexTest
IIm controller in a similar way. Each type of sensor requires a different
jumper configuration on the Model 498.65 transition module and a
different mezzanine card for the 498.65 ADDA Module.
Encoder
Transition
Module
+5V
Temposonics III
Transition Module
The FlexTest IIm
controller supports
both linear (shown) and
rotational encoders.
A Temposonics
sensor is usually
mounted inside
an actuator.
FlexTest IIm Controller Connections 183
