Cable Part Numbers
D
ESCRIPTION
Load cell, 661.xx w/MS connector
Load cell, 661.xx w/PT connector
Strain w/PT connector
LVDT
ADT–120º
Remote E-stop/X-head Interlock-load frame
Servovalve, 252.xx single
Servovalve, 252.xx dual
Jumper plug 2nd servovalve eliminator
Servovalve, 256.xx w/valve
Servovalve, 256.xx w/valve LVDT
ΔP stability
ΔP stability–dual cells
System ground–console MTD FlexTest
HSM on-off
HSM high-low 292.xx/298.xx
HSM on-off 292.xx/298.xx
413.07 Hydraulic interface to 298.12 prop HSM
497.05 Control Panel to 413.07
HPS (HSM power not included)
Y adapter at HPS
1. For CE configurations, there are CE versions of these cables. Refer to the System Cable Package
Selection-FlexTest drawing (PN 047-922-501) for these cable numbers.
196
FlexTest IIm Controller Connections
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Refer to the following table for cable part numbers used to connect test
hardware to the Model 497.01 Analog Chassis rear-panel connectors.
C
ABLE
046-440-6XX
046-440-2XX
050-120-0XX
046-440-3XX
048-341-1XX
054-145-4XX
046-440-1XX
046-440-4XX (in-phase); 046-440-5XX (out-of-phase)
039-705-901
046-440-1XX
046-440-8XX
047-927-6XX
048-049-6XX
005-402-3XX
039-705-3XX (24 V DC); 039-719-1XX (115 V AC)
039-705-5XX (24 V DC); 039-719-2XX (115 V AC)
039-708-1XX (24 V DC)
042-664-5XX (24 V DC)
042-075-701 (24 V DC)
039-708-7XX (24 V DC); 039-708-8XX (115 V AC)
005-407-801 (24 V DC); 005-401-801 (115 V AC)
P N
ART UMBER
1
1
MTS 793 Controller Hardware
1
1
1
