Installing 497/498 Electronics (FTIIm)

Analog Chassis Transition Modules

16 15 14 13 12
J38 J28 J37 J27 J36
Aux I/O Aux I/O Aux
System
J1601 J1501 J1401 J1301 J1201
J1602 J1502 J1402 J1302 J1202
Transition modules in the rear panel chassis

How To Install a Transition Module

64
Installation
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Transition modules located on the 497.01 rear panel provide signal
transfer between the 497 modules and external devices. One digital
transition module and up to eight analog transition modules can be
installed in this chassis. Each transition module plugs into the
backplane connectors and connects to two chassis slot locations.
Chassis Slot Number
11 10 9 8 7
J26 J35 J25 J34 J24 J33
I/O Aux I/O Aux I/O Aux
J1101 J1001 J901 J801 J701 J601
J1102 J1002 J902 J802 J702 J602
Analog Transition Modules
1. To install a transition module, remove the appropriate panel cover
from the analog chassis.
2. Plug the transition modules into the backplane connectors. Refer
the following table for transition module slot assignments.
M T
ODULE YPE
Analog Transition
Digital Transition
3. Replace the panel cover and fasten the screw locks on all D
connectors.
6 5 4 3 2 1
J23 J32 J22 J31 J21
I/O Aux I/O Aux I/O
J501 J401 J301 J201 J101
J202
J502 J402 J302 J102
Slot Assignment
S A
LOT SSIGNMENT
1–2, 3–4, 5–6, 7–8, 9–10, 11–12, 13–14, 15-16
A–B
MTS 793 Controller Hardware
A B
J41 J42
Com In Com Out
J43
J51 J50
XPTR In Intlk In DC Pwr
J44 J52
XPTROut IntlkOut
Digital
Transition
Modules
