Installing 497/498 Electronics (FTIIm)
M N
ODULE AME
493.55 A/D
493.56 D/A
493.57 DSPAD
493.59 Universal Encoder
70
Installation
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
ADDA II mezzanine cards
Converts up to eight external analog signals to digital signals for use
by the controller. This board requires the optional ADDA II module.
Converts up to eight internal digital signals to analog signals for use
by external devices. This board requires the optional ADDA II
module.
Converts up to eight external analog signals to digital signals for use
by the controller. A DSP chip provides digital filtering.
This board requires the optional ADDA II module.
Processes the signals from incremental, absolute, and Temposonics
III encoders. Each type of encoder requires a specific encoder
mezzanine card.
This board requires the optional ADDA II module.
F
UNCTION
MTS 793 Controller Hardware
