ADDA II Connections

112
FlexTest GT Controller Connections
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Each optional Model 493.50 ADDA II module supports up to four
mezzanine cards. Each installed mezzanine card is assigned a specific
ADDA II module front panel connector (J11–J18).
A hardware interface file (hwi) defines each type of module (and their
associated mezzanine cards) and maps each module location for the
system software. The hwi file and the physical locations for each type
of module and associated mezzanine cards must match. Also, the
ADDA II module address setting (on the module) must match the hwi
file address. For more information on the hwi file, see the MTS 793
Utility Software manual.
The following A/D or D/A mezzanine cards can be installed:
– Model 493.55 A/D
– Model 493.56 D/A
– Model 493.57 DSPAD
– Model 493.59 Universal Encoder
