Miscellaneous Conditioner Output Connections

Conditioning Sensors with Other MTS Products

MTS P
RODUCT
Model 408.81 Testing Panel/
Model 408.82 DC Conditioner
Model 409.81C Temperature Controller
Model 448.82/85 Test Controller with
Model 448.21/22 AC and DC Conditioners
Model 458.10/20 MicroConsole
Model 458.11/12/13/14 AC and DC
Controllers
150
FlexTest GT Controller Connections
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
The following table shows connector assignments for various MTS
products you can use with your the Model 493.10 Chassis.
S O
ENSOR
Sensor output is available at the rear-panel connector
J201 or J202.
Temperature output (via an analog signal) is available
at rear-panel connector J1.
Sensor output is available at rear-panel connector
J335.
Ensure sensor conditioners are set as follows:
X1: 2&3
X2: 2&3
®
with Sensor output is available at the MicroConsole rear-
panel connector Jx03. Connector Jx03 represents the
module location (J100–J600).
MicroConsole jumper Jx00 should be set to 1&2
(standard setting).
UTPUT
