Setting I/O Carrier Module Addresses; Setting Gres Iii Module Addresses; Setting Adda Ii Addresses - MTS Systems FlexTest IIm Manual

Setting I/O Carrier
module addresses
Setting GRES III
module addresses
Setting ADDA II
addresses
S 1 2
LOT
A PPC PPC
DDRESS
MTS 793 Controller Hardware
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
The dipswitch settings for address C20 is shown below. Increment the
rotary dipswitch as required to complete I/O Carrier module
addressing.
The dipswitch settings for address C08 is shown below. Increment the
rotary dipswitch as required to complete GRES III module addressing.
Use the onboard rotary dipswitches (S3, S2) and front panel rotary
dipswitch on each ADDA II module to set its address in accord with its
installed chassis slot as follows:
3 4 5
C40 C41
The rotary dipswitch settings for address C40 are shown below.
Increment the front panel dipswitch as required to complete ADDA II
module addressing.
Installing the 493.10 Chassis (FTGT)
6 7 8
C42 C43 C44
9 10
C4A C4C
Installation 43
