Optional ADDA II
For the optional ADDA II configuration, each encoder requires
Configuration
installation of a Model 493.59 Universal Encoder mezzanine card on
the Model 493.50 ADDA II module.
The Model 493.80 Encoder Transition module provides up to four
channels of encoder interface between the Model 493.50 ADDA II
module and various incremental, Temposonics, or other digital or
serial transducers.
MTS 793 Controller Hardware
110
FlexTest GT Controller Connections
