Installing the 493.10 Chassis (FTGT)

Stand-alone
installation
MTS 793 Controller Hardware
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
This chapter describes how to install the Controller chassis and
connect it to system components.
Installing the 493.10 Chassis (FTGT)
Installing the 493.02 Chassis (FlexTest SE)
Installing 497/498 Electronics (FTIIm)
The chassis can be installed in an equipment rack console or in a
standalone configuration.
The Model 493.10 Chassis weighs about 45 kg (100 lb) in stand alone
configuration.
Improper lifting techniques can cause strained muscles and back
injuries.
When lifting this chassis, take the appropriate precautions to prevent injuries
to yourself.
The standalone chassis can be placed on
the floor. The chassis location is limited
only by the length of the system cables.
The front panel of the chassis can be
removed to access the VMEbus plug-in
modules.
