Cable specification

Station Connections

J28 Hydraulic Service Manifold Connector

120
FlexTest GT Controller Connections
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
J54 Sys I/O is a 15-contact type D female connector.
• 15-contact type D male EMI connector.
• Backshell–EMI metallized plastic.
• Cable–24 AWG 4 connector with overall foil shield, (Belden 9534
or equivalent) with drain wire connected to metallized plastic
backshell at the chassis and to ground at the emergency stop
station.
Each Model 493.74 HSM transition board controls up to two stations. A
standard chassis configuration supports up to four stations. Each
station has the following connections
• J28 Hydraulic service manifold (HSM)
• J29 Load unit
• J43 Interlock
• J44 Remote run/stop
• J49 Auxiliary power
As a system option, the 493.10 chassis can be configured to support for
six or eight stations. See
231.
Connector J28 HSM controls the pressure of a hydraulic service
manifold. The controller software can configure the connector for
solenoid or proportional control of a 24 volt hydraulic service
manifold.
"Optional Station Configurations"
MTS 793 Controller Hardware
on page
