Model 497.05 Specifications (part 2 of 2)
P
ARAMETER
Interlock logic level Inputs
Dimensions
Height
Width
Depth
Model 498.22 Chassis Specifications (part 1 of 2)
P
ARAMETER
Dimensions
Height
Width
Depth
Weight
Rack mounting requirements:
Clearance-each side
Clearance-back
Clearance-top/bottom
Number of slots
Power requirements
FlexTest IIm Controllers
S
PECIFICATION
0 = 0 V DC
1 = 3.2 to 24 V DC
8.9 cm (3.5 in)
48.3 cm (19 in)
54.6 cm (21.5 in)
S
PECIFICATION
40 cm (15.75 in)
48.3 cm (19 in)
55.9 cm (22 in)
18 kg (40 lb) plus 0.5 kg (1 lb) per
module
5.7 cm (2.25 in) for air flow
15.3 cm (6.0 in) for cabling
No restrictions
12 VMEbus slots
100 - 120 V AC at 12 A between 50 - 60
Hz
220 - 240 V AC at 6 A between 50 - 60
Hz
