Encoder Connections

I/O Carrier Module
Configuration
MTS 793 Controller Hardware
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
For an ADDA configuration using an I/O Carrier module, each encoder
requires installation of a Model 493.47 Encoder Interface mezzanine
card on the Model 493.40 I/O Carrier board. The I/O Carrier connector
is based on the location of the mezzanine card installed on the board
of the I/O Carrier module.
FlexTest GT Controller Connections 109
