Jumper
configurations
228
Model 493.07 Converter Box
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Disconnect all cables from the Model 493.07 Converter Box before
removing the cover. Failure to do so could expose the operator to
dangerous voltages.
If the Converter Box remains connected to a 120 volt HPU, this voltage will
be present. Always remove all cable before removing the cover.
As shipped, the HPU interface on the Model 493.07 Converter Box is
compatible with Model 458.10/.20, 490.01, 493.xx, and 497.05
components.
The Model 493.07 Converter Box may be connected to other
controllers (as shown in the following table) using a "Y" cable.
Note If the Model 493.10 chassis is the only device connected to the
HPU, the jumper settings do not matter.
C
OMPATIBLE WITH
Model 458.05/.10/.20/.40
Model 490.01
Model 497.05
Model 413.05
Model 436.11
Model 407.05
Note The Model 493.07 Converter Box cannot be used with both groups
of controllers at the same time. If this functionality is needed, use
an HPU isolation box.
J
UMPERS
Standard jumper setting:
E10–E11install
E12–E13 install
E14–E15 install
E16–E17 install
E10–E13 remove
E14–E17 remove
Jumper change required:
E10–E11 remove
E12–E13 remove
E14–E15 remove
E16–E17 remove
E10–E13 install
E14–E17 install
