Ac Grounding; Power - MTS Systems FlexTest IIm Manual

System ground cable
(PN 039-709-2xx)
connected to other
components.
Chassis
ground is connected
through the power cord
connector.

AC grounding

Power

MTS 793 Controller Hardware
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Standalone
Configuration
Chassis ground cable
connected to the vertical
Signal common cable
connected to the power
(PN 005-402-3xx) connected
to the load frame or other
The AC power ground is through the power cord. The power cord
must be plugged into both the chassis and the power source for proper
grounding.
Proper grounding is required for safe operation.
It is also required to meet EMC emission and susceptibility requirements.
All equipment related to the chassis should be connected on the same
fused power circuit.
• The power supply can accept single-phase voltages within 90–264
V AC at frequencies between
• The maximum continuous power usage is approximately 1000 W.
The current draw depends on the local voltage supply. A 15 amp
line should be adequate for the chassis and the computer.
• The power supply automatically selects the proper voltage range
and line frequency.
Installing the 493.10 Chassis (FTGT)
Console
Configuration
(PN 037-766-102)
conductive rail.
(PN 037-766-101)
panel.
System ground cable
components.
.
47–63 Hz
Installation 39
