CJ51 Box In

P N
IN
1 +clk in
2 hyd high in
3 reset in
4 signal return
5 /intlk in
6 hyd low in
7 signal return
8 master/slave in
9 - clk in
10 hyd hi return out
11 reset return out
12 ground
13 /intlk return out
14 hyd low return out
15 ground
212
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Connector J51 Box In allows the Model 493.02 chassis to receive
clock, hydraulic, and interlock signals from another Model 493.02
chassis.
J51 Connector Pin Assignments
AME
+External clock input
Hydraulic high input
Interlock reset request input
Signal return for optically isolated inputs
Hydraulic interlock input
Hydraulic low input
Signal return for optically isolated inputs
Master -/Slave select input
- External clock input
Hydraulic high return output
Interlock reset return output
Signal ground
Hydraulic interlock return output
Hydraulic low return output
Signal ground
F
UNCTION
MTS 793 Controller Hardware
