Model 497.05 Hydraulic Control Panel

Hydraulic
Control Panel
32
Introduction
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
The hydraulic control panel provides the following functions.
• Control of up to four independent hydraulic service manifolds
• Hydraulic power supply control
• Interlock shutdown and latched indicators to show interlock status
• Programmable interlock station assignment
• Electrical power outputs to the hydraulic service manifolds and a
497.01 Analog Chassis
• Built-in emergency stop button and connections for a remote
emergency stop button
Refer to the Series 497 Electronics Product Information manual (PN
100-036-577) for details about configuring the hydraulic control panel
for your system.
