MTS Systems FlexTest IIm Manual page 223

Single Model 493.02 chassis with a 24 V PLC pump (506.52-.92) or 505 pump
493.02
Chassis
J25
HPS
Single Model 493.02 chassis with a non-PLC pump
039-713-8XX (24 V DC)
039-714-6XX (115 V AC)
493.02
Chassis
J25
HPS
Multiple Model 493.02 chassis' and 407 Controllers
493.02
Chassis
J25
HPS
493.02
Chassis
J25
HPS
407 Controller
J25
HPS
222
Hydraulic Configurations
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
039-713-7XX
Note The following three configurations have cables to support both 24 V
DC and 115 V AC control voltages. A Model 493.07 Converter Box is
available for each voltage (not both). Be sure the cables and
Converter Box are rated for the same voltage.
493.07
Converter Box
J1
HPS
039-713-8XX (24 V DC)
039-714-6XX (1 15 V AC)
493.07
Converter Box
J1
HPS
low level Y cable 039-713-501
OR
050-182-2XX
051-995-8XX (CE)
039-710-7XX (24 V DC)
039-710-8XX (115 V AC)
J25
HPS
039-710-7xx (24 V DC)
039-710-8xx (1 15 V AC)
J25
HPS
MTS 793 Controller Hardware
HPU
HPU
HPU
