Setting I/O Carrier Addresses - MTS Systems FlexTest IIm Manual

Installing the 493.10 Chassis (FTGT)
Placement of
VMEbus modules in
the front panel
chassis
Setting I/O Carrier
addresses
S 1 2
LOT
A PPC
DDRESS
42
Installation
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Use the dipswitch (S1) and rotary dipswitch (S2) on each I/O Carrier
module to set its address in accord with its installed chassis slot as
follows:
3 4 5
C20 C22 C24
6 7 8
C26 C28 C2A
MTS 793 Controller Hardware
9 10
C2C C2E
