Appendix A

Hydraulic Configurations

493 Chassis to 493.07
Converter Box
493.07 Converter Box to
HPU
Hydraulic pump
configurations
MTS 793 Controller Hardware
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
This section describes how to connect the Model 493.10 Chassis
(FlexTest GT Controllers) and the Model 493.02 Chassis (FlexTest SE)
to a variety of MTS hydraulic configurations.
Use the following connectors and cables to connect the Model 493.10/
02 Chassis to your HPU with a Model 493.07 Converter Box:
Note See Appendix B: Model 493.07 Converter Box on
jumpering information.
• 15 contact type D female EMI connector at J25 of the Model 493.73
HPU Transition module in the rear panel of the Model 493.10
Chassis. Backshell–EMI metallized plastic.
• 14 contact type CPC male connector at J1 of the Model 493.07
Converter Box chassis.
• Cable–24 AWG 10 conductor with overall foil shield, (Carol C0745
or equivalent) with drain wire connected to metallized plastic
backshell at the 493.10 chassis, and pin 14 at the Model 493.07
Controller Box chassis.
• 24 contact type CPC female connector at J25 of the Model 493.07
Converter Box chassis.
• 14 contact type MS connector at J1 of the HPU.
• Cable–18 AWG 14 conductor with overall foil shield, (Alpha 2248C
or equivalent) with drain wire connected to pin 4 of connector J25
and pin A of the pump connector.
The following diagrams show how to connect the chassis to a
hydraulic power unit.
• Single 493 chassis with a 24 V PLC (programmable logic
controller) pump or 505 pump
• Single 493 chassis with a non-PLC pump
• Multiple 493 chassis with a non-PLC pump
• Compatible controllers controlling a pump
page 227 for
Hydraulic Configurations 221
