Adjust Feedback
Signals
Task 4 Set up your program.
Using Function
Generator
Using Basic TestWare
Using MultiPurpose
TestWare
Programming Eurotherm Temperature Controllers
MTS 793 Controller Hardware
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
If you will monitor sensor feedback for data acquisition or control
feedback, adjust the incoming feedback signals.
Refer to "How to Configure an Externally Conditioned Feedback
Signal" in the MTS 793 Control Software manual for more information.
Define a program with the Function Generator, Basic TestWare, or
Multipurpose TestWare applications.
Refer to "How to Program with the Function Generator" in the MTS
793 Control Software manual.
The Basic TestWare application allows you to create simple test
programs that do not require complex signal management or mode
switches for station configuration files.
Refer to "Defining the Test Command" in the MTS 793 Control Software
manual.
Note It is good practice to use tapered wave shapes to apply the
program command to the external controller slowly.
To create more sophisticated test programs use the optional
MultiPurpose TestWare application.
Refer to the MTS 793 Application Software manual.for more
information.
When equipped with a GRES III plug-in module, your FlexTest IIm
controller can program and control one or more Series 2200/2400
Eurotherm Temperature Controllers via the J50 serial connectors on
the 498 RS-485 transition module.
FlexTest IIm Controller Connections 191
