J52 Box Out

P N
IN
1 +clk in
2 hyd high out
3 reset out
4 ground
5 /intlk out
6 hyd low out
7 ground
8 N/C
9 - clk out
10 hyd hi return in
11 reset return in
12 signal return
13 /intlk return in
14 hyd low return in
15 signal return
Jumper plug required
MTS 793 Controller Hardware
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Connector J52 Box Out allows the Model 493.02 chassis to send clock,
hydraulic, and interlock signals to another Model 493.02 chassis.
J52 Connector Pin Assignments
AME
+External clock output
Hydraulic high output
Interlock reset request output
Signal ground
Hydraulic interlock output
Hydraulic low output
Signal ground
No connection
- External clock output
Hydraulic high return input
Interlock reset return input
Signal return for optically isolated inputs
Hydraulic interlock return input
Hydraulic low return input
Signal return for optically isolated inputs
If connector J52 Box Out is not used, you must install a jumper plug
to maintain the integrity of the interlocks. Use jumper plug PN 100-057-
246 or jumper pins: 2-10, 3-11, 4-12, 5-13, 6-14, 7-15.
F
UNCTION
