In order to use one or more RSCs with your Model 493.10 Chassis, two
sections must be added to your hwi file, an RSC section and a GRES III
section.
Note Remote Station Controllers are not available with the optional 6 or 8-
station system configurations
Note If you specified RSC support when you ordered your test system,
these sections will be added to your hwi file at the factory. For
information on editing your hwi file to accommodate RSCs, see the
MTS 793 Utility Software manual.
The Model 493.10 Chassis can have several service connectors. There
are two types of connectors:
• The chassis connection monitors the power supply.
• The connection on the I/O Carrier module monitors the output of
each mezzanine card.
The J39 Power Monitor connector is located on the rear panel of the
chassis. It functions as test points for a service technician. It allows you
to check all of the power supply voltages along with the status of the
over-temperature sensor and the power fail circuit.
+5 Volts 2
3
+12 Volts
-12 Volts
4
+15 Volts 5
6
-15 Volts
+24 Volts 7
8
Ground
9
2.5 Volts Reference
Ground 11
Temperature 14
FlexTest GT Controller Connections 133
