HSM Connections

Cable specification
174
FlexTest IIm Controller Connections
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
The outputs provide 24 V DC to turn on the HSM solenoids.
From J28
Hydraulic I/O Solenoids
1 Low Pressure
2 DC Common
4 High Pressure
• P28 is a 4-contact CPC male connector (AMP Incorporated).
• Cable–18 AWG/2 connector type SJOOW-A for on/off HSMs 18
AWG/3 connector type SJOOW-A for high/low HSMs
• Cable assembly numbers:
– 290.XX HSM, on/off, 24 V DC, PN 039-705-3XX 18/2 SJO
– 290.XX/294.XX HSM, high/low, 24 V DC, PN 039-705-5XX 18/
3 SJO
– 298.11 HSM, on/off, 24 V DC, PN 039-708-1XX 18/2 SJO
Connector J28 controls the
To HSM
low-pressure and high-
pressure solenoids of a
hydraulic service manifold.
