Section 7: SCPI command reference
Example
:BATT:SIM:CURR:LIM 1
Also see
None

:BATTery[n]:SIMulator:CURRent:PROTection[:LEVel]

This command sets the current protection value in the battery simulator function.
Type
Command and query
Usage
:BATTery[n]:SIMulator:CURRent:PROTection[:LEVel] <value>
:BATTery[n]:SIMulator:CURRent:PROTection[:LEVel]?
:BATTery[n]:SIMulator:CURRent:PROTection[:LEVel]? DEFault
:BATTery[n]:SIMulator:CURRent:PROTection[:LEVel]? MINimum
:BATTery[n]:SIMulator:CURRent:PROTection[:LEVel]? MAXimum
[n]
<value>
Details
This command sets the current protection value in the battery simulator function.
This value cannot be changed when the simulation is in progress. If you modify this value without
pausing the simulation, error 704, "Not permitted while battery model is running" occurs.
Example
:BATT:SIM:CURR:PROT 2
Also see
None
7-40
Model 2281S-20-6 DC Power Supply and Battery Simulator Reference Manual
Affected by
Recall settings
Instrument reset
Power cycle
Channel number: For single-channel instruments, the value is 1
0.1 to 6.1 A
MINimum 0.10 A
MAXimum 6.10 A
DEFault 6.10 A
Set the current limit to 1 A.
Where saved
Save settings
Set the current protection to 2 A.
Default value
6.1 A
077114601 / March 2019
