:SYSTem:GPIB:ADDRess

This command sets the GPIB address.
Type
Command and query
Usage
:SYSTem:GPIB:ADDRess <n>
:SYSTem:GPIB:ADDRess?
[n]
Details
The address can be set to any address value from 1 to 30. However, the address must be unique in
the system. It cannot conflict with an address that is assigned to another instrument or to the GPIB
controller.
A new GPIB address takes effect when the command to change it is processed. If there are response
messages in the output queue when this command is processed, they must be read at the new
address.
If command messages are being queued (sent before this command has executed), the new settings
may take effect in the middle of a subsequent command message, so care should be exercised when
setting this attribute from the GPIB interface.
You should allow sufficient time for the command to be processed before attempting to communicate
with the instrument again.
*RST does not affect the GPIB address.
Example
:SYST:GPIB:ADDR 26
:SYST:GPIB:ADDR?
Also see
GPIB communication
077114601 / March 2019
Affected by
Not applicable
The GPIB address of the instrument (1 to 30)
(on page 2-69)
Section 7: SCPI command reference
Where saved
Nonvolatile memory
Sets the GPIB address and reads the address.
Output:
26
Default value
5
7-169
