Model 2281S-20-6 DC Power Supply and Battery Simulator Reference Manual

Data buffer

The data buffer captures measurements, instrument status, and the output state of the instrument.
The 2281S has only one buffer.
The data buffer provides the following statistics:
Average
Minimum
Maximum
Peak-to-peak
Standard deviation
You can perform the following operations on the data buffer from the front panel or the remote
interface:
Configure, store, and recall a reading buffer.
View reading buffer content.
Save reading buffer content to a USB flash drive.
Set reading buffer to next, always, or never fill mode.
Change the capacity of a reading buffer.
Clear a reading buffer manually or automatically.

Effects of reset and power cycle on buffer

The instrument clears the reading buffer when the instrument power is turned off and then on again.
077114601 / March 2019
Section 3: Functions and features
3-11
