Model 2281S-20-6 DC Power Supply and Battery Simulator Reference Manual

:BATTery[n]:SIMulator:CURRent?

This command queries the real-time battery current of the battery simulator.
Type
Query only
Usage
:BATTery[n]:SIMulator:CURRent?
[n]
Example
:BATT:SIM:CURR?
Also see
None

:BATTery[n]:SIMulator:CURRent:LIMit

This command sets the value of the current limit for stopping the discharging in the battery simulation function.
Type
Command and query
Usage
:BATTery[n]:SIMulator:CURRent:LIMit <value>
:BATTery[n]:SIMulator:CURRent:LIMit?
:BATTery[n]:SIMulator:CURRent:LIMit? DEFault
:BATTery[n]:SIMulator:CURRent:LIMit? MINimum
:BATTery[n]:SIMulator:CURRent:LIMit? MAXimum
[n]
<value>
Details
This command sets the value of the current limit for stopping the discharging in the battery simulation
function.
This value cannot be changed when the simulation is in progress. If you modify this value without
pausing the simulation, error 704, "Not permitted while battery model is running" occurs.
077114601 / March 2019
Affected by
Not applicable
Channel number: For single-channel instruments, the value is 1.
Affected by
Recall settings
Instrument reset
Power cycle
Channel number: For single-channel instruments, the value is 1
0 to 6.1 A
Section 7: SCPI command reference
Where saved
Not applicable
The real-time battery current is displayed.
Where saved
Save settings
Default value
Not applicable
Default value
0.1 A
7-39
