Model 2281S-20-6 DC Power Supply and Battery Simulator Reference Manual
Measurement Event Register
The bits of the Measurement Event Register are described in the following figure and table below it.
Bit
0 through 12
13
14 through 15
077114601 / March 2019
Figure 167: 2281S Measurement Event Register
Decimal Bit name
value
Not used Not used
8192 ISUM
Not used Not used
Appendix D: Status model
When set, indicates the following
has occurred:
NA
Summary of Measurement Instrument
Event Register and Measurement
Instrument Summary Event Register.
NA
D-17
