Section 7: SCPI command reference

:BATTery[n]:MODel:SAVE:INTernal

This command saves a battery model to the internal memory.
Type
Command only
Usage
:BATTery[n]:MODel:SAVE:INTernal <modelindex>
[n]
<modelindex>
Details
The 2281S can save up to nine battery models in the internal memory.
Before saving, the instrument will verify the number of values in the battery model to be saved. If it is
101, the model will be saved. Otherwise, error 701, "Model length not enough," is displayed.
If a model with the same name already exists, the newly saved one will replace the existing one.
Example
:BATT:MOD:SAVE:INT 1
Also see
None
7-36
Model 2281S-20-6 DC Power Supply and Battery Simulator Reference Manual
Affected by
Not applicable
Channel number: For single-channel instruments, the value is 1
1 to 9
Where saved
Not applicable
Save a battery model into the internal memory as model
1.
Default value
Not applicable
