Section 2: General operation
Source Settings menu for the power supply function
You can change the following settings by pressing the MENU key, moving focus to the Source
Settings icon, and pressing the Enter key.
Setting
V-Set
I-Limit
Output
Output Delay
Slew Rise
Slew Fall
Delay Rise
Delay Fall
Source Protection menu for the power supply function
This menu allows you to configure the protection settings.
Setting
Overvoltage Protection
Overcurrent Protection
Maximum Voltage
2-20
Model 2281S-20-6 DC Power Supply and Battery Simulator Reference Manual
Description
Configure the voltage setting using the numerical keys, soft keys, and
navigation control.
Configure the current setting using the numerical keys, soft keys, and
navigation control.
Turn on or off the output. You can also disable the output. Once output is
disabled, the output is off and the OUTPUT key is ignored.
Enable or disable output delay.
Set the rising rate for voltage source.
Set the falling rate for voltage source.
This menu option is only available if Output Delay is set to On. View the
delay time that the instrument waits before turning on the output.
This menu option is only available if Output Delay is set to On. View the
delay time that the instrument waits before turning off the output.
Description
Set the overvoltage protection limit of the source output to restrict the
maximum voltage level that the instrument can source.
Set the overcurrent protection limit of the source output to restrict the
maximum current level that the instrument can source.
Set the maximum voltage that can be set. This influences the voltage setting
range.
