Model 2281S-20-6 DC Power Supply and Battery Simulator Reference Manual

:BATTery[n]:SIMulator:HV

This command sets the high voltage (HV) in the battery simulator function.
Type
Command and query
Usage
:BATTery[n]:SIMulator:HV <value>
:BATTery[n]:SIMulator:HV?
:BATTery[n]:SIMulator:HV? DEFault
:BATTery[n]:SIMulator:HV? MINimum
:BATTery[n]:SIMulator:HV? MAXimum
[n]
<value>
Details
When the output voltage reaches this value, the digital I/O pin, which is set as Digital Out and HV
action, outputs a level signal.
Example
:BATT:SIM:HV 5
Also see
:BATTery:DIGital:LINE<line_index>:CONFigure
:BATTery:DIGital:LINE<n>:EDGe
077114601 / March 2019
Affected by
Recall settings
Instrument reset
Power cycle
Channel number: For single-channel instruments, the value is 1
0 to 21 V
MINimum 0.000 V
MAXimum 21.000 V
DEFault 21.000 V
(on page 7-28)
Where saved
Save settings
Set the high voltage as 5 V
(on page 7-27)
Section 7: SCPI command reference
Default value
21 V
7-41
