Section 3: Functions and features

Configuring a list

To set up a list from the front panel, select options from the SOURCE LIST screen.
To configure a list on the front panel:
1. Press the Menu key.
2. Under Source, highlight the List icon using either the navigation control or the soft keys.
3. Press the ENTER key. The SOURCE LIST screen is displayed.
4. Select the button next to List and press the ENTER key. The List Location screen is displayed.
5. Select a list location where you want to save the list and press the ENTER key. The 2281S
supports up to 9 list locations. You can also import a predefined list from an external USB flash
drive. For details, refer to
6. Use the Insert or Copy button to increase the points in the list. For details, refer to
copying points from the front panel
For details, refer to
You can use the Insert button to add one point with default settings before each specified point. The
default settings are: 0.000 V, 0.100 A, 0.100 s. You can also use the Copy button to copy the
selected settings for the point and insert a new point with the same settings before each point.
For an empty list, you can add the first point by selecting point 1 and pressing the ENTER key. The
first point is configured to the default settings.
3-40
Model 2281S-20-6 DC Power Supply and Battery Simulator Reference Manual
Figure 87: Source List screen
Importing a list from an external USB flash drive
(on page 3-41). Use the Delete button to delete the points.
Deleting points from the front panel
(on page 3-42).
(on page 3-41).
077114601 / March 2019
Inserting or
