Model 2281S-20-6 DC Power Supply and Battery Simulator Reference Manual
For 2281S, the expected values are shown in the following table.
Steps
9
10
Step 9
1. Before starting this calibration step, configure the shunt and power supply as shown in the
following table.
Model
2281S
2. Enter the shunt value and press the ENTER key.
3. Enter the measured result from the digital multimeter (DMM) and press the ENTER key.
4. After entering the data, the waiting window is displayed. You need to wait a few seconds for the
internal measurements and calculations. The step 10 window is displayed.
Step 10
Before starting this calibration step, configure the shunt and power supply as shown in the following
table.
Model
2281S
1. Enter the measured result from the digital multimeter (DMM) and press the ENTER key.
2. After entering the data, the waiting window is displayed. You need to wait a few seconds for the
internal measurements and calculations. Then the Save window is displayed.
3. You can save the calibration results or continue to the next calibration step. For the details on
saving, see
the calibration, press the Next soft key.
077114601 / March 2019
Maximum voltage
-2
6.06e V
–0.2 V
Shunt Power supply
5.05 Ω
Constant current mode
Shunt Power supply
5.05 Ω
Constant current mode
Saving calibration constants from the front panel
Appendix C: Calibration and adjustment
Minimum voltage
–9.09e
-2
V
–1.515 V
5.0 V 0.001 A
5.0 V 0.1 A
(on page C-19). If you want continue
