:BATTery[n]:TEST[:SOURce]:VOLTage[:LEVel]

This command sets the V-set value for charging and discharging in the battery test function.
Type
Command and query
Usage
:BATTery[n]:TEST:[SOURce]:VOLTage[:LEVel] <value>
:BATTery[n]:TEST:[SOURce]:VOLTage[:LEVel]?
:BATTery[n]:TEST:[SOURce]:VOLTage[:LEVel]? DEFault
:BATTery[n]:TEST:[SOURce]:VOLTage[:LEVel]? MINimum
:BATTery[n]:TEST:[SOURce]:VOLTage[:LEVel]? MAXimum
[n]
<value>
Details
This command specifies the V-set value, which determines whether the current direction is source or
sink. The current direction is switched automatically based on the terminal voltage of the battery
under test.
If the V-set value is greater than the terminal voltage of the battery under test, the instrument will start
to charge the battery.
If the V-set value is lower than the terminal voltage of the battery under test, the instrument will start
to discharge the battery.
Example
:BATT:TEST:VOLT 5
Also see
None
077114601 / March 2019
Affected by
Recall settings
Instrument reset
Power cycle
Channel number: For single-channel instruments, the value is 1
0 to 20 V
Section 7: SCPI command reference
Where saved
Save settings
Set the V-set value to 5 V.
Default value
0 V
