Model 2281S-20-6 DC Power Supply and Battery Simulator Reference Manual
General ratings
The general ratings and connections for the 2281S are listed in the following table.
Category
Supply voltage range
Output connections
Environmental conditions
Line fuse characteristics are shown in the following table.
Model
2281S-20-6
Terminology in this manual
Term
ESR
V
OC
Vt
Amp-Hour (A-H)
SOC
Battery model
V-Full
V-Empty
Dynamic
Static
077114601 / March 2019
Specification
100 V, 120 V, 220 V, 240 V; each range capable of 10% tolerance, 50 Hz or
60 Hz
Selectable by the line-voltage selector switch on the rear panel
See
Test connections
For indoor use only
Altitude: Maximum 2000 meters (6562 feet) above sea level
Operating: 0 °C to 40 °C, full accuracy to 80% relative humidity at up to 35 °C,
noncondensing
Storage: -20 °C to 70 °C, 5% to 95% relative humidity at up to 40 °C and 5% to
60% relative humidity above 40 °C at up to 70 °C
Pollution degree: 2
100 VAC/120 VAC source
250 V, 5 A, time delay
Explanation
Equivalent series resistance
Open-circuit voltage
Terminal voltage
Unit for battery capacity
State of charge
A profile of a battery that contains the information for Voc and ESR in different
states of charge
The voltage of the battery when it is fully charged
The voltage of the battery when it is fully discharged
During the dynamic battery simulation, the open voltage and SOC change with
the charging and discharging
During the static battery simulation, the open voltage and SOC stay the same
(on page 2-61).
220 VAC/240 VAC source
250 V, 2.5 A, time delay
Section 1: Introduction
1-7
