[:Source[N]]:List:rcl - Tektronix Keithley 2281 Series Reference Manual

Section 7: SCPI command reference
Example
:LIST:MCOMP STEP
Also see
Digital I/O (on page 3-22)

[:SOURce[n]]:LIST:RCL

This command recalls a specific list.
Type
Command and query
Usage
[:SOURce[n]]:LIST:RCL <listNumber>
[:SOURce[n]]:LIST:RCL?
[n]
<listNumber>
Details
Before you run a list, you need to recall this list. If you forget to recall a list, the last recalled list is
used. Sending the command :LIST:RCL? returns the active list number.
Example 1: Sweep list with BUS trigger (hold time type: TIME)
*RST
Define list
:LIST1:VOLT "1, 2, 3, 4, 5"
:LIST1:CURR "0.5, 1, 1.5, 2, 2.5"
:LIST1:DWEL "0.5, 0.5, 0.5, 0.5, 0.5"
:LIST:SAVE:INTe 1
:LIST:RCL 1
:LIST:MCOMP SWEEP
:LIST:HTIMe TIME
Define trigger model (sweep)
:ARM:SOUR BUS
:TRIG:COUN 5
Enable list mode
:LIST:STAT ON
:INIT
*TRG
7-140
Model 2281S-20-6 DC Power Supply and Battery Simulator Reference Manual
Affected by
Recall settings
Instrument reset
Power cycle
Channel number: For single-channel instruments, the value is 1
The list number: 1 to 9
After each list step, the instrument generates a
measure complete pulse.
Where saved
Saved settings
Reset the instrument and stop the trigger model
Program voltage list 1 with 5 points
Program current list 1 with 5 points
Program dwell list 1 with 5 points
Save list 1 to nonvolatile memory
Recall list 1
Select sweep mode
Set hold time type to TIME
Select the BUS arm source
Set the trigger count to list points, no need to set the
sample count for TIME mode
Enable list mode
Start the trigger model
Run the lists
Hold time is the sum of the dwell time of 5 points
All the readings will be stored in data buffer
Default value
0
077114601 / March 2019
