Model 2281S-20-6 DC Power Supply and Battery Simulator Reference Manual
Operation Event Register
The Operation Event Register records the unexpected operation of the power supply. Bit 13
summarizes operation outputs of the power supply. See the following figure and table below it for
details.
Bit
0 through 12
13
14 through 15
077114601 / March 2019
Figure 161: 2281S Operation Event Register
Decimal Bit name
value
Not used Not used
8192 ISUM
Not used Not used
Appendix D: Status model
When set, indicates the following
has occurred:
NA
Summary of Operation Instrument
Event Register and Operation
Instrument Summary Event Register.
NA
D-11
