Protection
IMx-M Manager
Important –Once the network configuration update has completed, the CMM
will be automatically restarted. During this restart period, connection to the PRM
will be lost. This means that any alarm or trip state will not have the associated
transient data during the restart.
2 - 78

Update Network Configuration updates the Network configuration file
(.imx) on a selected CMM. This will launch a file browser, which should be used
to select a correct Network configuration (*.imx) file.
Once selected, the process of updating the file to the CMM will start
automatically, with a status of the update being displayed on the IMx-M
Manager.

Syntax Help gives the user access to syntax help in the current prompt.
 It is a good practice to use this interface before the download of
any file to ensure that the communication has been established
with the CMM.
 If there is no access to syntax help, change the COM port and try it
again.
 When the syntax help access is established, the on-line device is
ready to be updated.

Set Debug On/Off prints/not prints measurement values of which the
CMM is currently measuring, for example, > PROCESS 69.617386 -
ANA10000004 on channel 4, DBID = 10000004.

Reset performs a software reset.

Get Events stores all events from the rack to a file in user readable
format. See Event Log for detailed event information.

Show Configuration displays the current measurement configuration of
the CMM.

Lock Display Window is a toggle button which locks/unlocks the contents
on the output display window. This can be useful when a user wants to copy
and paste information from the output window.

Clear Display Window clears the output window.

Advanced Debug Mode shall only be used by experienced installation
engineers in cooperation with SKF Condition Monitoring Center.
PRM Serial Interface
Use this menu option to show and enable the PRM Serial Commands.
