Protection
IMx-M Manager

Analog

Analog option displays all analog channels status.
The following fields are updated.

Value is the value in the assigned E.U.

Gap Value is the value in V.

Channel Status

Combined Meas

Combined Meas option displays all combined measurement channels status.
The following fields are updated.

Value is the value in E.U.

Channel Status
2 - 88
Figure 2 - 61.
Maintenance View - Analog Channel Status.
Figure 2 - 62.
Maintenance View - Combined Measurement Channel Status.
