Condition Monitoring Part Configuration

Condition Monitoring Module Serial (USB) Interface

Serial (USB) interface on a condition monitoring module is used to transfer the
configuration file
wise.
The USB port for CM network configuration is located on the front panel of each
condition monitoring module. See
Connections chapter for the physical location.
Selecting the correct USB Cable
Ensure that the correct (isolated) USB cable is selected for use. Do not use an ordinary
USB cable.
SKF Multilog On-Line System IMx-M
User Manual
Figure 4 - 16.
Mini-USB Connection to Protection Module.
created via IMx-M Manager to a condition monitoring module slot
Condition Monitoring Module (CMM)
Hardware
Hardware Configuration
network
in Drawings and
4 - 27
