CMM Circuit Faults

If any bit representation of a condition monitoring module circuit faults is not 0x0000,
then the protection module circuit fault relay will be triggered and the protection
module Circuit Fault LED will be indicating a circuit fault.
Table 2-15: Protection module diagnostics of CMM circuit fault – CM.
Protection Module Diagnostics of
Condition Monitoring Module Circuit Faults - CM
Bit Condition
Representation*
CF_RS485INT
0x0002
*Bit representation is in hexadecimal digits.
2 - 46
Comments
Internal RS485 communication error. Event log storage is not
available.
- Check that condition monitoring module is firmly positioned.
- Check the FW version in use.
