Register "Digital Ch Status" Bit Definition
Table 2-39: Register "Digital ch status" bit definition (TRUE=1).
Register "Digital Ch Status" Bit Definition
Bit representation*
(0x0000)
(No bit set)
0x0001
0x0002
0x0004
0x0008
0x0040
0x0080
*
Important:
- Bit representation is in hexadecimal digits.
- Bit representation can be a combination of more than one condition.
Example: Bit representation of 0x004A is equal to 0x0002 Ch alert +
Refer to
Register "Digital Ch Alarm Enable/Disable" Bit Definition
Table 2-40: Register "Digital ch Alarm enable/disable" bit definition (TRUE=1).
Register "Digital Ch Alarm Enable/Disable" Bit Definition
Bit representation*
*
Important:
- Bit representation is in hexadecimal digits.
- Bit representation can be a combination of more than one condition.
SKF Multilog On-Line System IMx-M
User Manual
Description
Ch not configured.
Ch enabled
Ch alert
Ch startup
Ch danger
Ch disarmed
Slot disarmed
Bit Representation of Combined Conditions
Description
(0x0000) Alarm Disabled
(No bit set)
0x0001 Alert Low
0x0002 Alert High
0x0004 Danger Low
0x0008 Danger High
0x0008 Ch danger +
0x0040 Ch disarmed
for combined conditions.
