Installation
The installation of an IMx-M rack must be carried out according to the instructions and
advice given in this manual. Any deviation from these directions can be made only after
consulting SKF Condition Monitoring Center Luleå.
Installation errors can lead to a situation where the system does not work as intended
and machinery faults go undetected. Therefore, contact the IMx-M application engineer
at the slightest doubt during the installation.
Important - Installation errors which require the involvement of SKF Condition
Monitoring Center Luleå personnel in order to rectify the start of the system, might
be debited.
Scenario
It is important to assess and evaluate the site where the system is to be installed.
Before beginning the installation, draw a plan of what the installation should look like
after the completion. Among other things, consider lengths of cables, where can
electrical power to the IMx-M racks be connected, where should the @ptitude Observer
Monitor be installed and positioned and who should analyze the data measured. Good
and thorough planning is the basis for a successful solution and installation.
SKF Multilog On-Line System IMx-M
User Manual
Figure 4 - 1.
IMx-M Rear Panel.
4
Hardware
4 - 1
