Import from Excel File

Import of an Excel file can only be performed at the Plant level and into an empty
configuration (see figure below):
Important - When importing a configuration from Excel, be aware that there
will be a loss of precision. For an example, an alarm value exported at 2001.781
will be imported as 2001.8.

Generate Report File

Generate Report can be executed from different nodes such as the plant, an area, a
rack or a slot. Right click on a desired node and select Generate report file.
The report is created in Portable Document Format (.pdf) or MS word (.doc) file format.
Note that if the report is generated from the plant or an area node, the report for each
rack will be created in separate files.
A report of an individual channel or relay is done by Print function.

Maintenance View

Maintenance View is intended to be used during system installation and maintenance
for troubleshooting and verification purposes. It makes it possible to verify
measurement values, alarms, sensor OK status and relay operation on all protection
channels. It also allows to create an AT (Acceptance Test) report.
Important - Events will not be saved in CMM during the maintenance mode. As
an effect of this username/configuration change information will NOT be stored by
the CMM when sending a configuration to the PRM during maintenance mode.
SKF Multilog On-Line System IMx-M
User Manual
Figure 2 - 59.
Importing IMx-M Configuration from an Excel Workbook.
