Hardware
Hardware Configuration
Table 4-2: DIP switch setting definition.
DIP Switch Setting

General Configuration

Analog Inputs

Three positions (P, A, B) and a shield (S) are available for each analog input sensor for
connecting sensor cables to each CMM + PRM slot. However, depending on the sensor
type, two or three positions are used.
Shield connection (S) is internally connected to instrumentation ground (IGND).
The DIP switch settings for connected analog sensors must be applied according to
tables, below.
For the location of analog channel DIP switches, refer to
Module.
Important -Grounding procedure must be handled with special care to prevent
ground loops. Be sure to read
thoroughly and understand them.
Important - Do NOT change DIP switch settings while the IMx-M rack is
powered-up, as this may cause damage and void warranty.
Important - Before powering up the IMx-M rack, make sure that DIP switch
settings are properly set to match the recommendations for the connected sensors.
Incorrect settings may cause permanent damage to the IMx-M rack.
4 - 14
0
1
"Signal
Definition
OFF
ON
DIP Switches on Protection
Grounding" and "Signal
SKF Multilog On-Line System IMx-M
Isolation" chapters
